Brinkmann
Spyder
Spyder
Regular price
$17,820.00 CAD
Sale price
$17,820.00 CAD
Regular price
Unit price
/
per
Description
"We started with a blank sheet of paper and created something extraordinary. The Spyder is a bold design statement that establishes new standards of versatility while advancing Brinkmann’s commitment to ultimate sonic performance. This daring design accommodates up to FOUR 9”-12” tonearms and allows maximum flexibility of placement regardless of the number of ‘arms installed. Utilizing our heated bearing and bespoke Sinus motor—both Brinkmann exclusives—developed for our flagship Balance, the belt-drive Spyder has benefitted from years of painstaking materials research to yield unmatched musicality."
|
Specifications |
Drive Mechanism | Belt drive using "Sinus" 4 -Phase, 12-Pole motor |
Power supply | External solid-state power supply, optional |
"RöNt II" vacuum-tube power supply | |
Bearing | Hydrostatic zero-maintenance bearing with heating |
for optimal tolerances | |
Platter | Resonance-optimized anodized aluminum alloy; |
crystal-glass platter mat / clamp | |
Chassis | Resonance-optimized anodized aluminum alloy |
Arm board | Movable (rotating) without play for simple and |
precise tonearm adjustment. Accepts all tonearms between | |
9" and 12" effective length, as well as several linear tracking | |
tonearms | |
Connectors | RCA, XLR or feed-through for tonearms with |
5-pin DIN connectors | |
RPM | 33 1/3 and 45, selectable by a switch |
LED indicator for speed | |
Deviation from nominal speed | 0.0% (adjustable) |
Fine adjustment of speed | ± 10% with trim pot |
Wow & Flutter | 0.07% linear, 0.035% weighted DIN 45507 |
Speed-up time | 6 / 8 seconds (33 1/3 / 45 rpm) |
Rumble (noise) | -66 dB (test record DIN 45544); -70 dB |
(measuring adapter) | |
Weight | Total 21 kg (Bearing w/ 1 jig and tonearm 5kg, |
Platter 10 kg, Power Supply 3 kg, Motor 3 kg) |
