"Steel & aluminium casework. Fully discrete & symmetrical gain stage. Balanced in & outputs. Cartridge loading options on front panel.
Phono Box S3 B is ready for our new True Balanced Connection. Single-ended RCA connections, quite literally, only use half of your cartridge's output. With one of our new True Balanced phono cables and an MC cartridge you'll hear details and dynamics, previously exclusive to only the most expensive phono stages.
Made in Europe by technicians, engineers and designers with decades of experience. Expert craftsmanship. Sustainable products with a long lifetime. Audiophile audio performance."
Available in black and silver.
| Input impedance: |
10, 50, 100, 1k, 47k ohms |
| Input capacitance: |
50, 150, 300, 400 pF |
| Gain (+ 6dB using XLR Out sockets): |
40, 45, 60, 65 dB |
| Signal / Noise ratio MM (40dB): |
103dBV, 110dBV - 'A' weighted |
| Signal / Noise ratio MC (60dB): |
85dBV, 90dBV - 'A' weighted |
| THD at 1 kHz: |
<0,001% MM, < 0,005% MC |
| THD (20Hz-20kHz): |
<0,008% MM, < 0,01% MC |
| RIAA-equalization curve accuracy: |
<0,3dB / 20Hz - 20kHz |
| Subsonic filter: |
at 20Hz with 18dB/octave |
| Input: |
1x 5-pin mini XLR / 1x pair RCA phono sockets |
| Line-level output: |
1x pair RCA, 1x pair XLR |
| Power supply DC: |
18V/500mA |
| Power consumption: |
18V/170mA DC, <0.5 W in standby |
| Dimensions: |
206 x 55 x 153 (164 with sockets) mm (W x H x D) |
| Weight: |
930g without power supply |
