Description
Dual mono fully balanced pre amplifier
The 740P is a dual-mono fully balanced differential design, following in the footsteps of the reference 850P pre amplifier. This “next generation” Evolution series preamplifier uses various recently in-house developed technologies that help create a level of performance that can be best described as astounding.
- Power supply voltage regulation includes i 2 DCf (Independent Inductive DC Filtering); 1 inductor for each and every IC in the audio circuit’s signal path – 24 stages in all.
- 4 stages of our M-LoVo (MOON Low Voltage DC regulation); a highly sophisticated circuit virtually free of noise, yielding exceptionally fast, precise, and very stable DC voltage.
- Gain offset adjustment of ±10dB for each line input.
- Fully compatible with 820S external power supply.
- Each line input is fully configurable to be “home theater ready”, whereby the 740P’s volume control is bypassed.
Specifications
- Circuit TopologyOpen loop
- Input Sensitivity 200mV - 4.0V RMS
- Input impedance 22,000Ω
- Gain 9dB
- Max. output voltage (XLR / RCA) 12V / 6V
- Signal-to-noise Ratio (20Hz-20kHz) 120dB @ full output
- Frequency response (full range) 5Hz - 100kHz ±0.1dB
- Crosstalk @ 1kHz -116dB
- Output impedance 50Ω
- THD (20Hz-20kHz)< 0.001%
- Intermodulation distortion, Immeasurable
- Shipping weight 35 lbs / 16 Kgs
- Dimensions (width x height x depth) 18.75 x 4.0 x 16.5 in.,47.6 x 10.2 x 41.9 cm
- Product specification
